优先发表栏目展示本刊经同行评议确定正式录用的文章,这些文章目前处在编校过程,尚未确定卷期及页码,但可以根据DOI进行引用。
显示方式:
Dimensional accuracy compensation method of large shaft grinding via residual error iteration with fuzzy approach
Changjie CHEN, Liping WANG, Shuailei FU, Dong WANG, Xuekun LI, Baojun LIANG
, doi: 10.51393/j.jamst.2023008
摘要:
Dimensional accuracy is one of the most important quality indicators of large shaft grinding, which directly affects the shaft service performance. Overcut/undercut caused by grinding wheel width and wear are the main factors affecting dimensional accuracy of large shaft grinding, which can be described by establishing physical models, and the physical models would be further used for compensation. However, the residual error always exists due to modeling uncertainty, and the residual error has nonlinear relation with compensation value, which is hard to completely eliminate. In order to solve the problem, this paper proposes a dimensional accuracy compensation method of large shaft grinding via residual error iteration with fuzzy approach. Two physical models are firstly established by considering the grinding wheel width and wear, respectively. The residual error after using these two models is further dealt with iteration, and the fuzzy approach is applied to dynamically calculate the compensation coefficients to improve dimensional accuracy while ensuring con-vergence. The experimental results show that the mean dimensional error is reduced 83% by using the pro-posed method, which is much better than other compensation methods. Dimensional accuracy is one of the most important quality indicators of large shaft grinding, which directly affects the shaft service performance. Overcut/undercut caused by grinding wheel width and wear are the main factors affecting dimensional accuracy of large shaft grinding, which can be described by establishing physical models, and the physical models would be further used for compensation. However, the residual error always exists due to modeling uncertainty, and the residual error has nonlinear relation with compensation value, which is hard to completely eliminate. In order to solve the problem, this paper proposes a dimensional accuracy compensation method of large shaft grinding via residual error iteration with fuzzy approach. Two physical models are firstly established by considering the grinding wheel width and wear, respectively. The residual error after using these two models is further dealt with iteration, and the fuzzy approach is applied to dynamically calculate the compensation coefficients to improve dimensional accuracy while ensuring con-vergence. The experimental results show that the mean dimensional error is reduced 83% by using the pro-posed method, which is much better than other compensation methods.
Design and analysis of 4SRRR legged wall-climbing robot
Zhongjin JU, Ke WEI, Yundou XU, Yongsheng ZHAO
, doi: 10.51393/j.jamst.2023005
摘要:
Currently, manual detection of wall welds and surface microcracks on ships and oil tanks is not only inefficient but also potentially hazardous. This study proposes a 4SRRR legged wall-climbing robot with redundant actuation, designed to accommodate the characteristics of permeable materials, to address this issue. First, the robot's gait is examined, followed by a thorough examination of its stability on both vertical and horizontal surfaces. For vertical surfaces, a statics analysis is conducted to prevent the risk of falling, whereas, for horizontal surfaces, the margin of stability is evaluated. To determine the required degrees of freedom for the robot to complete its assigned tasks, the screw theory is applied. The De-navit-Hartenberg (D-H) method is then used to analyze the forward and inverse kinematics of the robot. In addition, the La-grange balance method is used to analyze the swing leg's dynamics. A control algorithm for impedance is developed for situations in which the swinging leg collides with the ground. A prototype is then designed and tested to assess the wall-climbing performance and the efficacy of the impedance control strategy when the swinging leg experiences an impact. This research seeks to provide a solid theoretical foundation and technical support for the engineering application of wall-climbing robots, thereby enhancing the efficiency and safety of wall weld and surface microcrack detection processes in ships and oil tanks. Currently, manual detection of wall welds and surface microcracks on ships and oil tanks is not only inefficient but also potentially hazardous. This study proposes a 4SRRR legged wall-climbing robot with redundant actuation, designed to accommodate the characteristics of permeable materials, to address this issue. First, the robot's gait is examined, followed by a thorough examination of its stability on both vertical and horizontal surfaces. For vertical surfaces, a statics analysis is conducted to prevent the risk of falling, whereas, for horizontal surfaces, the margin of stability is evaluated. To determine the required degrees of freedom for the robot to complete its assigned tasks, the screw theory is applied. The De-navit-Hartenberg (D-H) method is then used to analyze the forward and inverse kinematics of the robot. In addition, the La-grange balance method is used to analyze the swing leg's dynamics. A control algorithm for impedance is developed for situations in which the swinging leg collides with the ground. A prototype is then designed and tested to assess the wall-climbing performance and the efficacy of the impedance control strategy when the swinging leg experiences an impact. This research seeks to provide a solid theoretical foundation and technical support for the engineering application of wall-climbing robots, thereby enhancing the efficiency and safety of wall weld and surface microcrack detection processes in ships and oil tanks.
Physical prior and Tikhonov regularization based residual stress inference method for annular parts using deformation force
Enning WANG, Xiaozhong HAO, Dong HE, Kai TANG
, doi: 10.51393/j.jamst.2023006
摘要:

Annular parts are widely utilized in high-end manufacturing, which are often manufactured by ring forging to meet the requirement on mechanical properties. However, residual stress (RS) is inevitably introduced in the forging process, which affects the working performance and reduces the service life of the part. Therefore, to counter the determent of RS, it is first necessary to accurately obtain it. Different from sheet or structural parts, the RS distribution in an annular part is more complex. Existing methods based on RS measurement and finite element prediction did not incorporate the RS prior, so the accuracy is influenced by the simplified assumption on RS distribution. This paper proposes a new RS inferencing method for annular parts based on the use of deformation force and physical prior. Firstly, the RS distribution prior of the annular blank after heat treatment is obtained by finite element simulation and the clustering algorithm. Then, the prior is employed to calculate the coefficient matrix to reflect the relationship between the deformation force and the RS. Finally, the Tikhonov regularization method is used to solve the deformation force-RS inverse problem. The effectiveness and feasibility of the proposed method are verified in the simulation and experiment, respectively, which shows that the integration of RS prior distribution is able to reduce the ill-condition of the solving process to obtain an accurate solution of RS distribution in an annular part.

Annular parts are widely utilized in high-end manufacturing, which are often manufactured by ring forging to meet the requirement on mechanical properties. However, residual stress (RS) is inevitably introduced in the forging process, which affects the working performance and reduces the service life of the part. Therefore, to counter the determent of RS, it is first necessary to accurately obtain it. Different from sheet or structural parts, the RS distribution in an annular part is more complex. Existing methods based on RS measurement and finite element prediction did not incorporate the RS prior, so the accuracy is influenced by the simplified assumption on RS distribution. This paper proposes a new RS inferencing method for annular parts based on the use of deformation force and physical prior. Firstly, the RS distribution prior of the annular blank after heat treatment is obtained by finite element simulation and the clustering algorithm. Then, the prior is employed to calculate the coefficient matrix to reflect the relationship between the deformation force and the RS. Finally, the Tikhonov regularization method is used to solve the deformation force-RS inverse problem. The effectiveness and feasibility of the proposed method are verified in the simulation and experiment, respectively, which shows that the integration of RS prior distribution is able to reduce the ill-condition of the solving process to obtain an accurate solution of RS distribution in an annular part.
